B Scan Ultra Scanner

• Turbid refractive media: ultrasound scanning is the best option to show the intra-ocular diseases.
• Somatometry of the eye
• Diagnosis before and after vitrectomy to confirm the range and extent of disease.
• Diagnosis and location of ocular trauma and intra­ocular foreign body.
• Intra-ocular tumor
• Diagnosis of exophthalmos
• Ocular and orbit hemodynamics
• Intrusive ultrasound to take out non-magnetic intra­ocular foreign body; tumor puncture under ultrasound guidance.

A- Scan:

• Display: B, B/B, 4B , B/A, A five-point measure, A single point measure
• Measure Range: A Five-point: 0~36mm; A single-point: 0~72mm
• Measure: ACD, Lens, Vitreous, CCT, AXL(immersion mode)
• Eye type: Normal/Aphakic/ Dense Catract/ Manual
• Measure mode: Immersion and contact, manual and auto measurement
• Calculation : std. Deviation, Average, auto average measurement of eight
• groups , result correction,
• Measurement method: A five-point measurement, A single-point measurement IOL formulas: SRK-II, SRK-T, BINKHORST, HOLLADAY, HOFFER-Q, HAIGIS,
• Display of random two formulas, calculation of degree of IOL, DEM of
• emmetropization of IOL, DAM of IOL, REEF after surgery,
• 100 groups of A scan results storage

A single point measurement:

• Magnification: x1.0, x2.0, x4.0
• Depth display: 0~36mm
• Delayed depth: 0~36mm

B-Scan:

• Scan mode : sector scanning, stepping motor with high precision
• Comparison of two or four images
• Depth selection: 24mm, 31 mm, 38mm, 42mm, 45mm,
• 49mm, 52mm, 56mm total 8 grades
• Compression Curve:8
• Post-processing:8
• Postponed depth range: 25-32mm Local zoom Up/down, L/R image tuning Color option:8
• Image storage :more than 10,000 images
• Cine loop:256 frames, measurement available
• Annotation: input character and arrow, Chinese/English available
• Disk management
• Measurement: distance, circumference, volume, angle, histogram, sectional view, etc.
• Report print: screen copy, IOL report, medical record with image etc. Language :Chinese/English
• USB2.0 to support U disk(file manipulation, software upgrade, one -key storage, etc)
• Internal D disk(4G) for data, image , report, movie clip
